FT-20 – Fog Machine

ft20 1
ft 20 3ft20 2

FT-20 is a battery-operated portable smoke generator, capable of providing long time operations with massive fog output.

Categories: , Brands: Series:

Product Description

FT-20 is a battery-operated portable smoke generator, capable of providing long time operations with massive fog output.

• Two power supplying modes available: DC 12 volt battery or switching power adaptor, which enables the machine to be operated in AC power

environment. (between AC 100 and 240 volt)

* Switching power adaptor is an optional accessory.

• No preheat or reheat time is needed. push the button, consistent fog output can be generated right away.

• In the battery mode, the machine can produce approximately 11 minutes continuous fog output.

• In the switching power supply mode, fog output can keep going, NON-stop, as long as there are fog liquid in the tank.

• Rotary knob allows users to set the fog output volume.

• Optional remote controller with on/off and fog volume adjustment function..

• DMX control access.

Specification

- Input voltage

- Rated power
- Warm-up time
- Fluid consumption
- Fluid tank capacity
- Compatible fluid
- Ambient temp. range
- Control

- DMX channels
- Connection
- Optional accessories

- Dimension

- Weight

DC 12V (Battery)
AC 100-240V, 50-60Hz (Battery charger)
600W
1 second (approx.)
16 ml/min
0.4 Liter (0.11gallon)
Antari FLM Fog Fluid
0 °C - 40 °C (32 °F-104 °F)
DMX512, Manual,
Wireless (Optional)
Cable Remote (Optional)
1 channel
XLR 3-pin (DMX)
WTR-20 Wireless Remote
Z-3 Cable Remote
FT-20S Power Base
L293 W108 H238 mm
(L11.54 W4.25 H9.37 inch)
8.5 kg (18.74 lbs)
